MixPac Mixcoat 2-part Spray System DPF Pneumatic with Included Flex Hoses (DPF 1500-15 or DPF 1500-30) (128965 or 128989)
Regular price
$ 2,999.99 USD
MedMix Mixpac MixCoat Pneumatic Sprayable Dispenser (DPF 1500-15 or DPF 1500-30) (128965 or 128989) for two component spray-on materials. Can be used to dispense 1:1, 2:1, 3:1, or 4:1 ratio MixCoat cartridges.
Specifications
- Application: Spray-Style Dispensing of Coatings, Adhesives, and Sealants
- Pneumatic / Air powered dispenser with full force and power of Pneumatics.
- Separate Air Tank and hand-held spray nozzle assembly
- Cartridge capacity: 1500ml, 1125ml, 1000ml, 940ml
- Cartridge ratio: 1:1, 2:1, 4:1, 10:1
- Designed for Mixcoat F System Cartridges
Included accessories:
- Either 1.5meter or 3meter hose assembly with mixing dispenser/sprayer attachment
- converter kit for 1:1, 2:1, 3:1, 4:1 ratio plunger discs.
Dispensers & Hose Systems available
| Dispenser & Hose Information | Compatible Ratios | ||||||
| Dispenser System | Part ID | Part Number | Hose Length | 1:1 | 2:1 | 3:1 | 4:1 |
| DM dispenser manual | 128966 | DM 1500-01 | Hoses Separate | ✓ | ✓ | ✓ | ✓ |
| DPD dispenser pneumatic | 128962 | DPD 1500-01 | Hoses Separate | ✓ | ✓ | ✓ | ✓ |
| DPS dispenser pneumatic with Air Spray HookUp | 128963 | DPS 1500-01 | Airhose Attachment Included, Hoses Separate | ✓ | ✓ | ✓ | ✓ |
| DPF dispenser pneumatic flex spray with flexible hose and Trigger-Mixing Sprayer | 128965 | DPF 1500-15 | 1.5-Meter Hose System | ✓ | ✓ | ✓ | ✓ |
| 128989 | DPF 1500-30 | 3-Meter Hose System | ✓ | ✓ | ✓ | ✓ | |
Use with These MixCoate F-System Cartridges
And These Cartridges use F-System Mixing Nozzles, take a look at recommended accessories in the scroll bar above.
| Sulzer Mixcoat DPF 1500-15 & DPF 1500-30 |
||||
| Cartridge Part Number | Cartridge System | Volume (ml) | Ratio | Material |
| AF 1500-01-14-01 | AF | 1500 | 1:1 | PP |
| AF 1500-01-30-01 | AF | 1500 | 1:1 | PA |
| AF 1125-02-14-01 | AF | 1125 | 2:1 | PP |
| AF 1125-02-30-01 | AF | 1125 | 2:1 | PA |
| AF 1000-03-14-01 | AF | 1000 | 3:1 | PP |
| AF 1000-03-30-01 | AF | 1000 | 3:1 | PA |
| AF 940-04-14-01 | AF | 940 | 4:1 | PP |
| AF 940-04-30-01 | AF | 940 | 4:1 | PA |
Piston Insertion Tools: And for efficient filling and sealing, use these piston insertion devices a when filling the cartridges manually.
| Piston Insertion Device | ||||
| Volume (ml) | Ratio | Part | ||
| 1500 | 1:1 | PIDQ 1500-01-01 | ||
| 1125 | 2:1 | PIDQ 1125-02-01 | ||
| 1000 | 3:1 | PIDQ 1000-03-01 | ||
| 940 | 4:1 | PIDQ 0940-04-01 | ||
